Marin ALCATRAZ
€ 1.539,00
-Beschrijving-
SLOPESTYLE
PUMP TRACK
SKATE PARK
The Series 3 aluminum frame is built for the hard knocks and is stiff enough for lightning-fast acceleration and tough enough for the heavy hits. Short stays keep manuals easy and ambidextrous cable routing means you can run your brake on the left or right of the bars. There’s a 100mm Manitou Expert coil fork, front and rear Tektro hydraulic disc brakes, Vee Tire rubber and plenty of bombproof Marin components. Best of all, it’s available in two frame sizes, regular and long
-Specs-
| FRAME | Series 3 6061 Aluminum, 26” Wheels, 135x10mm Horizontal Single Speed Dropouts, 73mm Threaded BB, ISCG 05 Tabs |
| FORK | Manutou Circus Expert, 26″, 100mm Travel, Coil Spring, Taper Steerer Tube, 20x110mm Thru Axle |
| REAR SHOCK | – |
| RIMS | Marin Custom Extrusion, 27mm Inner, Pinned Joint |
| HUB REAR | Forged Alloy, 135x10mm, Bolt-On, Quad Sealed Bearings, Disc, 32H |
| HUB FRONT | Forged Alloy, 110x20mm, Disc, 32H |
| SPOKE | 14g Black Stainless Steel |
| TIRES | Vee Tire Co. XCV 26×2.25”, LSG Compound, Wire Bead |
| DERAILLEUR REAR | – |
| DERAILLEUR FRONT | – |
| SHIFT LEVER | – |
| CRANKSET | Marin Forged Alloy, Alloy 32T Chainring, 104mm BCD |
| BOTTOM BRACKET | External Sealed Cartridge Bearings |
| CHAIN | KMC HL-1 |
| CASSETTE | 14T Single Speed Cog |
| BRAKE FRONT | Tektro HDM275 Hydraulic Disc, 160mm Rotor |
| BRAKE REAR | Tektro HDM275 Hydraulic Disc, 160mm Rotor |
| BRAKE LEVERS | Tektro HDM275 Hydraulic |
| HANDLEBAR | Marin Riser, 6061 Double Butted Aluminum, 31.8mm at center bulge, 38mm Rise, 750mm Width, 4º Up, 9º Back |
| STEM | Marin 3D Forged Alloy, 31.8mm clamp, 40mm extension |
| GRIPS | Marin Single Clamp Locking |
| HEADSET | FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8″ x 1 1/2” |
| SEATPOST | Marin Alloy, 30.9mm |
| SADDLE | Marin DJ Saddle |
| PEDALS | Alloy Platform |
| EXTRAS | Marin Chain Tension Device |
Specifications, pricing, and availability are subject to change without notice.
-Geometry-
| Size | SHORT | LONG |
| A STACK | 575 | 580 |
| BREACH | 385 | 430 |
| C HEADTUBE ANGLE | 69° | 69° |
| D HEADTUBE LENGTH | 115 | 120 |
| E SEATTUBE ANGLE | 69° | 69° |
| F SEATTUBE LENGTH | 320 | 320 |
| G TOPTUBE EFFECTIVE | 600 | 646 |
| H BB HEIGHT | 317 | 317 |
| I BB DROP | 22 | 22 |
| J CHAINSTAY | 395 | 395 |
| K WHEELBASE | 1037 | 1083 |
| L STANDOVER HEIGHT | 370 | 400 |
| M FORK OFFSET | 42 | 42 |
| SEATPOST DIAMETER | 30.9 | 30.9 |
| HANDLEBAR WIDTH | 750 | 750 |
| STEM LENGTH | 40 | 40 |
| CRANK LENGTH | 170 | 170 |
All lengths in millimeters
-Tech-
SERIES 3 ALUMINUM FRAME
The Alcatraz features a 6061 Series 3 alloy frame, with a burly double butted tubesets for the best ride quality and stiffness, tapered headtubes for maximum strength on big jumps, and horizontal drop out with slotted IS disc brake tabs.
SHORT CHAINSTAYS
We have optimized the chainstay length of the Alcatraz to make sure you can have the shortest chainstays possible, giving you the ability to pop a wheelie or manual anywhere at anytime.
135X10MM HORIZONTAL DROPOUTS
The Alcatraz features 135x10mm horizontal dropouts — the standard in dirt jump technology for axle and dropout strength.
DIRT JUMP SPECIFIC SUSPENSION FORK
100mm travel X-Fusion Slant DJ-specific fork with air spring, compression and rebound damping, and tapered alloy steerer tube.
